Features:
Technical specification:
• Measure DVB-S and DVB-S2 signals (920-2150MHz) • Spectrum-analyzer with zoom function • EasyFind satellite identifi cation for faster installations • Super bright 3” LCD display • Very sensitive, easy to maximize weak and strong signals • Digital MER, BER, QPSK (DVB-S), 8PSK (DVB-S2) and S/N-ratio • Readout NIT -gives Satellite ID and TV/Radio-channel info • X-pol. function for optimize LNB skew • DiSEqC according to level 1.0, 1.1 and 1.2 • LNB voltage 13/18V, 22KHz tone switch • Stores up to 99 memory positions • RS232 for PC-connection (up/download) • Built in, rechargeable battery • Nice & small, only 1,5Kg complete with carrying case
Input frequency: 920-2150MHz. Sat-TV min level in: About 35 dBuV (noise). Sat-TV max level in: About 100 dBuV. Input/output impedance: 75 Ohm, F-connectors. Measuring method (analog): Spectrum analyzer Signal presentation on LCD -display in form of thermometer scales. Pitch-tone, highest tone on loudspeaker. Measuring method (Digital): BER (bit error rate) MER (Modulation error rate) SNR (signal/noise-ratio) Constellation (QPSK & 8PSK) Max-level: Thermometer scales showing max. Maxhold function. BER, MER, SNR, QPSK and 8PSK Satellite-identification: Yes, by reading out the NIT in the bitstream. Info about the TV and Radio channels. Memory: Up to 99 transponders can be stored with name. Memory search: The instrument scans the memory positions and presents the matching transponders. Presentation: On LCD 3” PC-connection: Yes, RS232-output Power out: Yes, 13-18V. 22 kHz tone: Yes, on/off. DiSEqC: Yes, all 1.0 and 1.1. Also Toneburst on/off. DiSEqC actuator: Built in positioner for DiSEqC 1.2, SatScan and SatSelect. Battery: Rechargable 12v, 1.25amp/hour. Accessories: Nylon carrying-case. Power-supply of 230V13.5V,1.7A BNC/F-adapter. Operational: About 1 hour on a fully charged Battery. Weight: 1.5kg incl.battery & carrying case.
