Features: • Very handy and easy to use Satellite-TV meter. • ”EasyFind”- satellite identification for super fast installations. • Very sensitive, easy to maximize weak and strong signals • Digital BER and S/N-ratio • Spectrum-analyzer 920-2150 MHz with zoom function • Super bright LCD display with backlite • Readout NIT -tells Satellite ID and TV/Radio-channel info • DiSEqC according to level 1.0, 1.1 and 1.2 • LNB voltage 13/18V, 22KHz tone switch • Easy to connect with PC for upgrades. • Built in, rechargeable battery • Nice & small, less then 1kg incl. battery. • CE- approved, Made in Sweden
Technical specification: Input frequency: 920-2150MHz. Sat-TV min level in: About 35 dBuV (noise). Sat-TV max level in: About 100 dBuV. Input impedance: 75 Ohm, F-connector Measuring method: EasyFind satellite-search. BER (bit error rate) S/N (signal/noise-ratio) Spectrum analyzer Max-level: Thermometer scale showing max. Maxhold function. BER and S/N showing max values. Pitch-tone, highest tone on loudspeaker. Satellite-identification: Yes, by reading out the NIT in the bitstream. Info about the TV and Radio channels. Satellite locks on: FEC, Symbol-rate Frecuency, 13/18v, 22kHz. Presentation: On LCD with backlite. Power out: Yes, 13-18V. 22 kHz tone: Yes, on/off. DiSEqC: Yes, 1.0 and 1.1. Upgrade software: Yes. Battery: Built in, rechargable LiP-type. Operational: About 1 hour fully charged. Weight: Less then 1kg incl.battery. Accessories: Power-supply of 230V12V,1.2A
