Emitor International AB Ostmastargrand 12 120 40 Stockholm, Sweden Phone: +46 8 5333 40 70 Fax: +46 8 5333 40 71
• Spectrum-analyzer 950-2150MHz.
• DVB/S S/2 -receiver 920-2150MHz.
• Super bright 5” 16:9 TFT-LCD color display.
• Automatic Satellite identification.
• Readout of NIT - gives SAT ID and TV/Radio-channel info.
• Digital BER and S/N-ratio (DVB-S, S/2).
• QPSK and 8PSK constellation diagram.
• DVB-S (Free to Air) and SAT-analog TV-picture.
• LNB voltage 13/18V, 22KHz tone switch.
• DiSEqC according to level 1.0, 1.1 and 1.2.
• SatCr-control (UniCable).
• Favourite channel list (100 channels) for FTA DVB-S.
• Lots of memory positions for spectrum pictures.
• RS232 for PC-connection (up/download).
• Rechargeable Li-Ion battery.
Input frequency: 920-2150MHz.
Sat-TV min level in: About 35 dBuV (noise).
Sat-TV max level in: About 90 dBuV.
Sat-TV attenuation: 15 dB attenuator on/off.
Display of signallevel
(analog):
dB on LCD/monitor. Pitch-tone.
Sat-TV accuracy: ±1½ dB (at +20° C).
DVB-S S/2 Digital display
of signallevel:
S/N (signal/noise-ratio) BER (bit error
rate) Constellation (QPSK and 8PSK).
Satellite-indentification: Yes, by reading out the NIT in the
Bitstream. Info about the TV and Radio
channels.
TV standard: Multi TV/ (PAL, NTSC, SECAM).
KU- C-band: Yes, selectable.
Input impedance: 75 Ohm, BNC-con.
Picture-screen: 5” 16:9 TFT-LCD monitor
Menus: On LCD 64x128.
Memory: - Lots of spectrum pictures can be stored
with name.
Stored spectrum can be mixed for easy
identification of satellite.
-“Maxhold”-function.
Favouritechannels: Both analog and digital frequencies can
be stored (with name).
100 DVB-S Free to Air channels can be
stored in a favourite channel-list.
PC-connection: RS232-output and PC-software.
Sat-TV power out: Yes, 13-18V.
Sat-TV control: 22 kHz, DiSEqC SatCr (UniCable).
DiSEqC: Yes, all 1.0 and 1.1. 1.2, Toneburst on/off.
DiSEqC actuator: Built in positioner for DiSEqC 1.2,
Battery: Rechargable 12v, 3.5 amp/hour.
Weight: About 4 kg incl. battery.
Accessories: Nylon carrying-case.
Power-supply of 220v/13.5v, 1.7amp.
F-adapters.
Features:
Technical specification:
