Emitor International AB Ostmastargrand 12 120 40 Stockholm, Sweden Phone: +46 8 5333 40 70 Fax: +46 8 5333 40 71
Features:
• Perfect for digital terrestrial installations (ISDB-T).
• Handy spectrum-analyzer for frequency 45-862MHz.
• Easy digital readout of BER and SNR.
• Ready for Mpeg2 and Mpeg4 signals.
• Analog signal level reads out in dBuV.
• Presents one channel readout with high resolution or six channels
simultaneously or the complete spectrum.
• Very sensitive, easy to maximize weak and strong signals.
• Built in beeper (pitch tone) and maxhold function.
• Aerial power output, 0V, 5V, 12V and 24V.
• Built in, rechargeable battery.
• Power supply.
• Carrying-case enclosed.
• Made in Sweden.
Technical specification:
Input frequency: 45-860 MHz.
Input level: 30-80 dBuV.
Input impedance: 75 Ohm, F-connector.
Short circuit protection: Automatic fuse on antennainput.
Measuring method: in digital Two bars showing BER (bit error rate)
and SNR (signal/noice ratio). in analog One bar showing dBuV in high resolution
or 6 bars showing strength of 6 channels.
Spectrum display. Pitch tone indication from beeper.
Signal-level readout: Digital BER and SNR values.
Analog dBuV with maxholdfunction.
Power out: 0V, 5V,12V and 24V on/off.
Power supply/charger: 10 -18V DC (Centerpin +).
Display: Back-lighted 128x64 Pixels LCD.
Power consumption: 500mA.
Battery: 8x AA rechargeable batteries of 1200mA each.
Weight: 0.3 kg.
Dimensions: 185 x 115 x 50 mm.
Accessories: Powersupply 12V DC, 1A.
Rubber-case.
